TT ELECTRONICS / BI TECHNOLOGIES - 6187R10KL1.0 - Rotary Potentiometer, Without Stop, 10 kohm, 1 Turns, Linear, 1 W, ± 10%, 6180
- Track Resistance: 10kohm
- No. of Turns: 1Turns
- Track Taper: Linear
- Power Rating: 1W
- Resistance Tolerance: ± 10%
- Product Range: 6180 Series
- Potentiometer Mounting: Panel
- Shaft Diameter: 6.34mm
- No. of Gangs: 1
- Adjustment Type: Screwdriver Slot
- Shaft Length: 12.7mm
- SVHC: No SVHC (20-Jun-2016)
- Body Diameter: 22.2mm
- Bush Thread Length: 9.53mm
- External Length / Height: 11.6mm
- Insulation Resistance: 1000Mohm
- Operating Temperature Max: 125°C
- Operating Temperature Min: -65°C
- Operating Temperature Range: -65°C to +125°C
- Resistor Element Material: Conductive Plastic
- Temperature Coefficient: -800ppm/°C
- Voltage Rating: 400V
