AMPHENOL LTD - 62GB-12E16-08SN - Circular Connector, 62GB, Box Mount Receptacle, 8 Contacts, Solder Socket, Bayonet, 16-8
- Product Range: 62GB Series
- Circular Connector Shell Style: Box Mount Receptacle
- No. of Contacts: 8Contacts
- Circular Contact Type: Solder Socket
- Coupling Style: Bayonet
- Insert Arrangement: 16-8
- Connector Body Material: Aluminium Alloy Body
- Connector Body Plating: Olive Drab Zinc
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Insert Rotation: N
- Service Class: Environmentally Sealed
- Equivalent Military Specification: MIL-DTL-26482 Series
- SVHC: No SVHC (15-Jan-2019)
- Approval Category: MIL-C-26482
- Colour: Olive Drab
- Contact Resistance: 5mohm
- Current Rating: 13A
- IP / NEMA Rating: IP67
- Insulation Resistance: 5000Mohm
- Moulding Material: Aluminium Alloy
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Proof Voltage: 2100VDC
- Size: 16
- Voltage Rating VAC: 500V
- Working Voltage: 700VDC
