WURTH ELEKTRONIK - 691361300006 - Pluggable Terminal Block, 3.81 mm, 6 Ways, 26AWG to 16AWG, 1.5 mm², Screw, 10 A
- Pitch Spacing: 3.81mm
- No. of Positions: 6Ways
- Wire Size (AWG): 26AWG to 16AWG
- Conductor Area CSA: 1.5mm²
- Wire Connection Method: Screw
- Rated Current: 10A
- Rated Voltage: 300V
- Product Range: -
- SVHC: Lead (15-Jan-2019)
- Connector Mounting: Cable Mount
- Connector Type: Terminal Block, PCB
- Contact Material: Phosphor Bronze
- Contact Plating: Tin Plated Contacts
- Lead Spacing: 3.81mm
- Wire Size AWG Max: 16AWG
- Wire Size AWG Min: 26AWG
