VISHAY - 715C20DKT50 - Ceramic Disc Capacitor, 500 pF, 20 kV, -20%, +80%, Y5U, Screw
- Capacitance: 500pF
- Voltage Rating: 20kV
- Product Range: 715C Series
- Capacitance Tolerance: +80%, -20%
- Dielectric Characteristic: Y5U
- Lead Spacing: -
- Capacitor Terminals: Screw
- Operating Temperature Min: -30°C
- Operating Temperature Max: 85°C
- SVHC: Lead (15-Jan-2019)
- Body Diameter: 22.4mm
- Capacitance Tolerance ±: +80%, -20%
- External Depth: 22.4mm
- External Length / Height: 25.4mm
- External Width: 22.4mm
- Height: 24.5mm
- Operating Temperature Range: -30°C to +85°C
- Voltage Rating V DC: 20000V
