WURTH ELEKTRONIK - 749013021 - Transformer, LAN, PoE, 2 Port, 10/100 Base-T, 1500VAC, 350µH, 1:1 Turn Ratio
- Transformer Type: 10/100 Base-T, PoE
- No. of Ports: 2 Port
- Transformer Mounting: Surface Mount
- Operating Temperature Min: 0°C
- Operating Temperature Max: 70°C
- Product Range: -
- SVHC: No SVHC (15-Jan-2019)
- Current Rating: 350mA
- External Depth: 6.22mm
- External Width: 14.99mm
- For Use With: LAN Application
- Inductance: 350µH
- Length: 13.64mm
- Transformer Inductance: 350µH
- Transformer Series: WE-LAN
- Transformer Type: Encapsulated
- Turns Ratio: 1
