ALPHA WIRE - 78132 SL005 - Multicore Cable, EcoGen™ EcoCable® Mini, Screened, 2 Core, 22 AWG, 0.382 mm², 100 ft, 30.5 m
- Cable Shielding: Screened
- No. of Cores: 2Core
- Wire Gauge: 22AWG
- Conductor Area CSA: 0.382mm²
- Reel Length (Imperial): 100ft
- Reel Length (Metric): 30.5m
- Jacket Colour: Slate
- No. of Max Strands x Strand Size: 19 x 34AWG
- Conductor Material: Tinned Copper
- Jacket Material: MPPE
- External Diameter: 3.3mm
- Voltage Rating: 300V
- Product Range: EcoCable Mini Series
- SVHC: No SVHC (15-Jan-2019)
- Alpha Type Number: EcoGen EcoCable Mini
- Operating Temperature Max: +80°C
- Operating Temperature Min: -40°C
