7914H-001-000 Switch, Pushbutton, THT, SPST Bourns

BOURNSUGS :7914H-001-000 Code de commande:1607973

Prix:
Prix ​​promotionnel€2,09

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (83 unité)

Documents et téléchargements

description

BOURNS - 7914H-001-000 - Tactile Switch, 7914, Top Actuated, Through Hole, Round Button, 300 gf, 100mA at 16VDC

  • Product Range: 7914 Series
  • Actuator Orientation: Top Actuated
  • Switch Mounting: Through Hole
  • Actuator Style: Round Button
  • Actuating Force: 300gf
  • Contact Rating: 100mA at 16VDC
  • Switch Dimensions (L x W): 5mm x 5mm
  • IP Rating: IP67
  • Illumination: Non Illuminated
  • SVHC: No SVHC (15-Jan-2018)
  • Actuation Type: Top
  • Contact Configuration: SPST
  • Contact Current DC Max: 100mA
  • Contact Current Max: 100mA
  • Contact Voltage DC Max: 16V
  • Contact Voltage DC Nom: 16V
  • Operating Force: 300gf
  • Switch Operation: Off-On
  • Switch Terminals: Solder
