OMRON - A6H-0101 - DIP / SIP Switch, 10 Circuits, Slide, Surface Mount, SPST, 24 VDC, 25 mA
- No. of Circuits: 10Circuits
- Switch Actuator Style: Slide
- Switch Mounting: SMD
- Contact Configuration: SPST
- Contact Voltage DC Max: 24VDC
- Contact Current DC Max: 25mA
- Product Range: A6H Series
- Switch Type: DIP Unsealed
- Actuation Type: Flat
- Contact Resistance: 200mohm
- Dielectric Strength VDC: 300V
- Insulation Resistance: 100Mohm
- Lead Spacing: 1.27mm
- No. of Pins: 20Pins
- No. of Positions: 10Ways
- Operating Force Max: 0.49N
- Operating Force Min: 0.29N
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
- Pin Configuration: DIL
- Pitch Spacing: 1.27mm
- Switching Capacity: 25 mA
