OMRON - A6R-102RF - Rotary Coded Switch, A6R, Through Hole, 10 Position, 24 VDC, BCD, 25 mA
- Product Range: A6R Series
- Switch Mounting: Through Hole
- No. of Switch Positions: 10 Position
- Switching Voltage: 24VDC
- Output Code: BCD
- Switching Current: 25mA
- Switch Construction: Sealed
- Actuator Level: Flushed
- Actuation Type: Flat
- Actuator Type: Screwdriver Slot
- Contact Current DC Max: 25mA
- Contact Current Rating: 25mA
- Contact Resistance: 200mohm
- Contact Voltage DC Max: 24V
- Insulation Resistance: 100Mohm
- Lead Spacing: 2.54mm
- No. of Positions: 10Ways
- Operating Force: 1.96N
- Operating Temperature Max: 80°C
- Operating Temperature Min: -25°C
- Pitch Spacing: 2.54mm
- Switch Type: DIP
- Switching Capacity: 25 mA
