TDK - ACM2012-900-2P-T001 - Filter, Common Mode, ACM Series, 90 ohm, 400 mA, 2mm x 1.2mm x 1.2mm
- Rated Current: 400mA
- Inductance: -
- Product Range: ACM Series
- Impedance: 90ohm
- Common Mode Filter Case: 2mm x 1.2mm x 1.2mm
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Core Material: Ferrite
- DC Current Max: 400mA
- DC Current Rating: 400mA
- DC Resistance Max: 0.19ohm
- External Depth: 0.5mm
- External Length / Height: 1.3mm
- External Width: 2mm
- Height: 1.3mm
- Inductor Case Style: 0805 [2012 Metric]
- Inductor Type: Common Mode Choke
- No. of Pins: 4Pins
- Operating Temperature Max: 85°C
- Operating Temperature Min: -25°C
- Voltage Rating: 50V
