KEMET - ALS30A333KE040 - Electrolytic Capacitor, 33000 µF, 40 V, ± 20%, Screw, 18000 hours @ 85°C
- Capacitance: 33000µF
- Voltage Rating: 40V
- Product Range: ALS30 Series
- Lifetime @ Temperature: 18000 hours @ 85°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Screw
- Diameter: 51mm
- Lead Spacing: 22.2mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 82mm
- ESR: 0.012ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- AC Ripple Current @ 100Hz: 14.2A
- AC Ripple Current @ 10kHz: 16.7A
- Capacitance Tolerance ±: ± 20%
- Climatic Category: 40/085/56
- ESR Frequency: 100Hz
- ESR Temperature: 20°C
- External Length / Height: 82mm
- Leakage Current: 7920mA
- Operating Life Temperature: 85°C
- Operating Temperature Range: -40°C to +85°C
- Operating life Time: 18000h
- Ripple Current AC: 14.2A
- Ripple Current Frequency: 100Hz
- Ripple Current Temperature: 85°C
