PHOENIX CONTACT - 1629109 - Sensor Connector, M23 PRO Series, M23, Female, 17 Positions, Crimp Socket - Contacts Not Supplied
- Switch Operation: Off-On
- Contact Configuration: SPDT
- Illumination: Non Illuminated
- Product Range: A Series
- Contact Current Max: 20A
- Switch Mounting: Panel
- Contact Voltage AC Nom: 250V
- Switch Terminals: Quick Connect, Solder
- Contact Voltage DC Nom: 30V
- SVHC: No SVHC (15-Jan-2019)
- Actuation Type: Lever
- Bush Thread Length: 6.5mm
- Contact Current AC Max: 20A
- Contact Current DC Max: 20A
- Contact Resistance: 10mohm
- Contact Voltage AC Max: 250VAC
- Contact Voltage DC Max: 30VDC
- Dielectric Strength VDC: 1500VAC
- External Depth: 21mm
- External Length / Height: 23mm
- External Width: 33mm
- Height: 58.5mm
- IP / NEMA Rating: IP67
- Insulation Resistance: 1000Mohm
- Insulation Resistance Voltage: 500VDC
- Lever Length: 17.5mm
- No. of Electrical Operations: 20000
- No. of Mechanical Operations: 40000
- Operating Force Max: 29.4N
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
- Panel Cutout Diameter: 12.5mm
- Shaft Diameter: 6mm
- Single Flat Panel Cut-out Diameter: 11.5mm
