EPCOS - B32521C3473K000 - General Purpose Film Capacitor, Metallized PET Stacked, Radial Box - 2 Pin, 0.047 µF, ± 10%
- Capacitance: 47000pF
- Voltage Rating: 250V
- Capacitor Dielectric Type: PET (Polyester)
- Capacitance Tolerance: ± 10%
- Product Range: B32521 Series
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 10mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 125°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Capacitance Tolerance ±: ± 10%
- Capacitor Mounting: Through Hole
- Climatic Category: 55/100/56
- External Depth: 7mm
- External Length / Height: 13mm
- External Width: 4mm
- Flammability Rating: UL94V-0
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +100°C
- Tolerance +: 5%
- Tolerance -: 10%
- Voltage Rating V DC: 250V
- Voltage Rating VAC: 160V
