EPCOS - B32674D8474K000 - Power Film Capacitor, Metallized PP, Radial Box - 2 Pin, 0.47 µF, ± 10%, DC Link, Through Hole
- Capacitance: 0.47µF
- Voltage Rating: 1.05kV
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 10%
- Product Range: B32674 Series
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 27.5mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Voltage Rating V DC: 1.05kV
