B43501A9477M000 Cap, 470µF, 400V, Alu Elec, Snap In EPCOS

EPCOSUGS :B43501A9477M000 Code de commande:1200430

Prix:
Prix ​​promotionnel€20,50

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (114 unité)

Documents et téléchargements

description

EPCOS - B43501A9477M000 - Electrolytic Capacitor, Long Life, 470 µF, 400 V, ± 20%, Snap-In, 10000 hours @ 85°C

  • Capacitance: 470µF
  • Voltage Rating: 400V
  • Product Range: B43501 Series
  • Lifetime @ Temperature: 10000 hours @ 85°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Quick Connect, Snap-In
  • Diameter: 35mm
  • Lead Spacing: 10mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Height: 45mm
  • ESR: 0.15ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Capacitance Tolerance ±: ± 20%
  • Climatic Category: 40/085/56
  • External Length / Height: 45mm
  • External Width: 35mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +85°C
  • Operating life Time: 10000h
  • Ripple Current AC: 2.6A
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 400V
