B72207S0301K101 Varistor, 23.0J, 300VAC EPCOS

EPCOSUGS :B72207S0301K101 Code de commande:1004364

Prix:
Prix ​​promotionnel€0,42

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (76442 unité)

Documents et téléchargements

description

PHOENIX CONTACT - 1004364 - MODULE MARKER CARRIER, PMB

  • Voltage Rating VAC: 300V
  • Voltage Rating V DC: 385V
  • Product Range: StandarD Series
  • Clamping Voltage Vc Max: 775V
  • Varistor Case Style: Disc 7mm
  • Varistor Type: Metal Oxide Varistor (MOV)
  • Peak Surge Current @ 8/20µs: 1.2kA
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Peak Energy (10/1000uS): 23J
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CECC, CSA, UL
  • Body Diameter: 9mm
  • Capacitance: 90pF
  • Clamping Voltage: 775V
  • Clamping Voltage @ 8/20µs Max: 775V
  • External Length / Height: 11.5mm
  • Lead Length: 30mm
  • Operating Temperature Range: -40°C to +85°C
  • Peak Pulse Current IPP @ 8/20µs: 1200A
  • Suppressor Type: Varistor
  • Surge Current: 1.2kA
  • Transient Energy: 23J
  • Varistor Voltage: 470V
  • Varistor Voltage @ 1mA: 423V
  • Varistor Voltage @ 1mA Max: 517V
  • Varistor Voltage Tolerance +: 10%
