B72207S0350K101 Varistor, 2.5J, 35VAC EPCOS

EPCOSUGS :B72207S0350K101 Code de commande:1004373

Prix:
Prix ​​promotionnel€0,57

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (3143 unité)

Documents et téléchargements

description

EPCOS - B72207S0350K101 - TVS Varistor, MOV, 35 V, 45 V, StandarD, 110 V, Disc 7mm, Metal Oxide Varistor (MOV)

  • Voltage Rating VAC: 35V
  • Voltage Rating V DC: 45V
  • Product Range: StandarD Series
  • Clamping Voltage Vc Max: 110V
  • Varistor Case Style: Disc 7mm
  • Varistor Type: Metal Oxide Varistor (MOV)
  • Peak Surge Current @ 8/20µs: 250A
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Peak Energy (10/1000uS): 2.5J
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CECC, CSA, UL
  • Body Diameter: 9mm
  • Capacitance: 1050pF
  • Clamping Voltage: 110V
  • Clamping Voltage @ 8/20µs Max: 110V
  • External Length / Height: 11.5mm
  • Lead Length: 30mm
  • Operating Temperature Range: -40°C to +85°C
  • Peak Pulse Current IPP @ 8/20µs: 250A
  • Suppressor Type: Varistor
  • Surge Current: 250A
  • Transient Energy: 2.5J
  • Varistor Voltage: 56V
  • Varistor Voltage @ 1mA: 50.4V
  • Varistor Voltage @ 1mA Max: 61.6V
  • Varistor Voltage Tolerance +: 10%
