EPCOS - B82422T1472K000 - Wirewound Inductor, 4.7 µH, 1.5 ohm, 50 MHz, 220 mA, 1210 [3225 Metric], B82422T
- Inductance: 4.7µH
- Product Range: B82422T Series
- DC Current Rating: 220mA
- High Frequency Inductor Case: 1210 [3225 Metric]
- Inductor Construction: Wirewound
- DC Resistance Max: 1.5ohm
- Inductance Tolerance: ± 10%
- Self Resonant Frequency Min: 50MHz
- SVHC: No SVHC (27-Jun-2018)
- Core Material: Ferrite
- Inductor Case Style: 1210 [3225 Metric]
- Q Factor: 30
- Q Test Frequency: 7.96MHz
- Reel Quantity: 2000
