EPCOS - B82475M1223M000 - Wirewound Inductor, 22 µH, 0.1 ohm, 1.95 A, 10.4mm x 10mm x 5.8mm, B82475M1
- Inductance: 22µH
- RMS Current (Irms): 1.95A
- Inductor Construction: Wirewound
- Saturation Current (Isat): 2A
- Product Range: B82475M1 Series
- Power Inductor Case: 10.4mm x 10mm x 5.8mm
- DC Resistance Max: 0.1ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
