CAMDENBOSS - CMFTB/3 - Fused Terminal Block, 3 Ways, 1.5 mm², Screw, 20 A, 450 V
- No. of Positions: 3Ways
- Wire Size (AWG): -
- Conductor Area CSA: 1.5mm²
- Wire Connection Method: Screw
- Rated Current: 20A
- Rated Voltage: 450V
- Fuse Size Held: 5mm x 20mm
- Product Range: -
- SVHC: No SVHC (15-Jan-2019)
- Approval Category: UL 94V-0
- Breaking Capacity Current AC: 250A
- Colour: Grey
- Connector Mounting: Cable Mount
- Contact Material: Brass
- Contact Plating: Nickel Plated Contacts
- Current Rating: 13A
- External Length / Height: 28mm
- External Width: 20mm
- Flammability Rating: UL94V-0
- Fuse Current: 13A
- IP / NEMA Rating: IP20
- Operating Temperature Max: 125°C
- Operating Temperature Min: -20°C
- Pitch Spacing: 10mm
- Voltage Rating AC Max: 450V
- Voltage Rating VAC: 450V
- Wire Area Size Max: 2.5mm²
