CMX200D3 SSR, Sip, 200VDC/3a, 3-10VDC In SENSATA/Crydom

SENSATA/CRYDOMUGS :CMX200D3 Code de commande:1936439

Prix:
Prix ​​promotionnel€69,71

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documents et téléchargements

description

SENSATA/CRYDOM - CMX200D3 - Solid State Relay, CMX Series, DIP, DC Output, SPST-NO, 3 A, 200 VDC, PCB, Through Hole, DC Switch

  • Contact Configuration: SPST-NO
  • Load Current: 3A
  • Operating Voltage Max: 200VDC
  • Relay Mounting: PCB
  • Relay Terminals: Through Hole
  • Switching Mode: DC Switch
  • Operating Voltage Min: 0VDC
  • Control Voltage Min: 3VDC
  • Control Voltage Max: 10VDC
  • Product Range: CMX Series
  • SVHC: No SVHC (12-Jan-2017)
  • Control Voltage DC Max: 10VDC
  • Control Voltage DC Min: 3VDC
  • Control Voltage Range: 3V DC to 10V DC
  • Control Voltage Type: DC
  • Forward Current If: 15mA
  • Input Current: 15mA
  • Input Voltage: 3V DC to 10V DC
  • Isolation Voltage: 2.5kV
  • Load Current Min: 0mA
  • Load Voltage Max: 200VDC
  • Load Voltage Range: 0V DC to 200V DC
  • On State Resistance Max: 0.2ohm
  • Output Type: MOSFET
