CN024D24 SSR, Sip, 24Vdc/3.5A, 24Vdc Input SENSATA/Crydom

SENSATA/CRYDOMUGS :CN024D24 Code de commande:1821822

Prix:
Prix ​​promotionnel€35,46

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (138 unité)

Documents et téléchargements

description

SENSATA/CRYDOM - CN024D24 - Solid State Relay, CN Series, Mini SIP, SPST-NO, 3.5 A, 24 VDC, PCB, Through Hole, Zero Crossing

  • Contact Configuration: SPST-NO
  • Load Current: 3.5A
  • Operating Voltage Max: 24VDC
  • Relay Mounting: PCB
  • Relay Terminals: Through Hole
  • Switching Mode: Zero Crossing
  • Operating Voltage Min: 0VDC
  • Control Voltage Min: 15VDC
  • Control Voltage Max: 30VDC
  • Product Range: CN Series
  • SVHC: No SVHC (12-Jan-2017)
  • Control Voltage DC Max: 30VDC
  • Control Voltage DC Min: 15VDC
  • Control Voltage Range: 15V DC to 30V DC
  • Control Voltage Type: DC
  • Current Rating: 7mA
  • Input Voltage: 0V DC to 24V DC
  • Load Voltage Range: 15V DC to 30V DC
  • Operating Voltage Range: 0V DC to 24V DC
