CSTBV1/36 TB, Wire TO BRD, 36POS, 16AWG Camdenboss

CAMDENBOSSUGS :CSTBV1/36 Code de commande:3882676

Prix:
Prix ​​promotionnel€41,96

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (35 unité)

Documents et téléchargements

description

CAMDENBOSS - CSTBV1/36 - Standard Terminal Block, Wire to Board, CSTBV1, 36 Contacts, 5 mm, Terminal Block, PCB, PCB Mount

  • Product Range: CSTBV1 Series
  • No. of Contacts: 36Contacts
  • Pitch Spacing: 5mm
  • Connector Type: Terminal Block, PCB
  • Connector Mounting: PCB Mount
  • Wire Size AWG Max: 16AWG
  • Wire Size AWG Min: 30AWG
  • Contact Plating: Tin Plated Contacts
  • Contact Material: Phosphor Bronze
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Category: UL 94V-0
  • Block Orientation: Through Hole Right Angle
  • Colour: Grey
  • Conductor Area CSA: 1.5mm²
  • Flammability Rating: UL94V-0
  • No. of Positions: 36Ways
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -20°C
  • Rated Current: 10A
  • Rated Voltage: 300V
  • Thread Size: M3
  • Voltage Rating AC Max: 250V
  • Voltage Rating VAC: 250V
  • Wire Area Size Max: 1.3mm²
  • Wire Connection Method: Clamp
