CAMDENBOSS - CSTBV2/36 - Standard Terminal Block, Wire to Board, CSTBV2, 36 Contacts, 5.08 mm, Terminal Block, PCB
- Product Range: CSTBV2 Series
- No. of Contacts: 36Contacts
- Pitch Spacing: 5.08mm
- Connector Type: Terminal Block, PCB
- Connector Mounting: PCB Mount
- Wire Size AWG Max: 16AWG
- Wire Size AWG Min: 30AWG
- Contact Plating: Tin Plated Contacts
- Contact Material: Phosphor Bronze
- SVHC: No SVHC (15-Jan-2019)
- Approval Category: UL 94V-0
- Block Orientation: Through Hole Right Angle
- Colour: Grey
- Conductor Area CSA: 1.5mm²
- Current Rating: 12A
- Flammability Rating: UL94V-0
- No. of Positions: 36Ways
- Operating Temperature Max: 125°C
- Operating Temperature Min: -20°C
- Rated Current: 10A
- Rated Voltage: 300V
- Screw Material: Steel
- Screw Plating: Zinc
- Thread Size: M3
- Voltage Rating AC Max: 250V
- Voltage Rating VAC: 250V
- Wire Area Size Max: 1.3mm²
- Wire Connection Method: Clamp
- Wire Size (AWG): 30AWG to 16AWG
