SENSATA/CRYDOM - CWD2425P - Solid State Relay, SPST-NO, 25 A, 280 Vrms, Panel Mount, Screw, Zero Crossing
- Contact Configuration: SPST-NO
- Load Current: 25A
- Operating Voltage Max: 280Vrms
- Relay Mounting: Panel
- Relay Terminals: Screw
- Switching Mode: Zero Crossing
- Operating Voltage Min: 24Vrms
- Control Voltage Min: 3VDC
- Control Voltage Max: 32VDC
- Product Range: CW24 Series
- SVHC: No SVHC (12-Jan-2017)
- Approval Bodies: CE, CSA, VDE
- Approval Category: UL Recognised
- Blocking voltage: 600V
- Control Current Typ: 10mA
- Control Voltage DC Max: 32VDC
- Control Voltage DC Min: 3VDC
- Control Voltage Range: 3V DC to 32V DC
- Control Voltage Type: DC
- External Depth: 58.4mm
- External Length / Height: 33mm
- External Width: 45.7mm
- I2t: 1500s
- Insulation Resistance: 1000Mohm
- Isolation Voltage: 4kV
- Leakage Current: 1mA
- Load Current Max: 25A
- Load Current Min: 0.15A
- Load Current RMS Max: 25A
- Operating Temperature Max: 80°C
- Operating Temperature Min: -40°C
- Operating Voltage Range: 24Vrms to 280Vrms
- Output Type: SCR
- RMS Load Current Min: 0.15A
- RMS Load Voltage Max: 280V
- RMS Load Voltage Min: 24V
