D2MQ-1 Microswitch, Plunger Omron

OMRONUGS :D2MQ-1 Code de commande:9901906

Prix:
Prix ​​promotionnel€4,90

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (525 unité)

Documenten en downloads

description

OMRON - D2MQ-1 - Microswitch, Snap Action, Plunger, SPDT, Solder, 500 mA, 30 VDC

  • Microswitch Type: Snap Action
  • Microswitch Actuator: Plunger
  • Contact Configuration: SPDT
  • Switch Terminals: Solder
  • Contact Current Max: 500mA
  • Contact Voltage DC Nom: 30VDC
  • Product Range: D2MQ Series
  • Contact Voltage AC Nom: -
  • Operating Force Max: 1.18N
  • Actuation Type: Plunger
  • Actuator Type: Pin Plunger
  • Contact Current AC: 500mA
  • Contact Current DC Max: 500mA
  • Contact Current Rating: 500mA
  • Contact Resistance: 100mohm
  • Contact Voltage DC Max: 30V
  • External Depth: 8.1mm
  • External Length / Height: 6.5mm
  • External Width: 2.6mm
  • Fixing Centres: 4mm
  • Fixing Centres LxW: 4mm
  • Insulation Resistance: 100Mohm
  • No. of Electrical Operations: 10000
  • No. of Mechanical Operations: 30000
  • Operating Force: 1.18N
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -15°C
  • Pre-travel: 0.4mm
