SENSATA/CRYDOM - D53TP50C - Solid State Contactor, 50 A, 530 Vrms, 32 VDC, Zero Crossing, Panel, Screw
- Load Current: 50A
- Operating Voltage Max: 530Vrms
- Control Voltage Max: 32VDC
- Switching Mode: Zero Voltage Turn On
- Contactor Mounting: Panel
- Contactor Terminals: Screw
- Operating Voltage Min: 48Vrms
- Control Voltage Min: 4VDC
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
- Control Current Max: 35mA
- Control Current Min: 24mA
- Control Voltage DC Max: 32VDC
- Control Voltage DC Min: 4VDC
- Control Voltage Range: 4V DC to 32V DC
- Control Voltage Type: DC
- External Depth: 79.7mm
- External Length / Height: 35.4mm
- External Width: 103.9mm
- Fixing Centres: 5.1mm
- Fixing Centres LxW: 47.6 x 92mm
- I2t: 2520s
- Isolation Voltage: 4kV
- Leakage Current: 3mA
- Load Current RMS Max: 50A
- Must Actuate Voltage: 4VDC
- Must Release Voltage: 1VDC
- No. of Phases: Three Phase
- Operating Temperature Max: 80°C
- Operating Temperature Min: -40°C
- Operating Voltage Range: 48Vrms to 530Vrms
- Output Type: Random-Fire, Zero-Crossing
- RMS Load Current Min: 0.1A
- RMS Load Voltage Max: 530V
- RMS Load Voltage Min: 48V
