D6C90F1LFS Switch, SPNO, Square, Black C&K Components

C&K COMPONENTSUGS :D6C90F1LFS Code de commande:1201367

Prix:
Prix ​​promotionnel€3,07

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (2489 unité)

Documents et téléchargements

description

C&K COMPONENTS - D6C90F1LFS - Tactile Switch, D6, Top Actuated, Through Hole, Square Button, 130 gf, 100mA at 32VDC

  • Product Range: D6 Series
  • Actuator Orientation: Top Actuated
  • Switch Mounting: Through Hole
  • Actuator Style: Square Button
  • Actuating Force: 130gf
  • Contact Rating: 100mA at 32VDC
  • Switch Dimensions (L x W): 12mm x 11.4mm
  • IP Rating: -
  • Illumination: Non Illuminated
  • SVHC: No SVHC (15-Jan-2019)
  • Actuation Type: Top
  • Actuator / Cap Colour: Black
  • Colour: Black
  • Contact Configuration: SPST-NO
  • Contact Current DC Max: 100mA
  • Contact Current Max: 100mA
  • Contact Current Rating: 100mA
  • Contact Resistance: 100mohm
  • Contact Voltage AC Max: 100V
  • Contact Voltage DC Max: 32V
  • Contact Voltage DC Nom: 32V
  • External Diameter: 12mm
  • External Length / Height: 11.5mm
  • External Width: 11.4mm
  • Insulation Resistance: 100000Mohm
  • Lead Spacing: 5mm
  • No. of Mechanical Operations: 250000
  • Operating Force: 1.3N
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -20°C
  • Operating Time: 3ms
  • Row Pitch: 5mm
  • Stroke Length Max: 0.8mm
  • Switch Operation: Off-(On)
  • Switch Terminals: Solder
