BLOCK - DCT12-1 - Linear Power Supply, Non-Stabilised, ITE, 1 Outputs, 12 W, 12 V, 1 A
- No. of Outputs: 1Outputs
- Output Power Max: 12W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 1A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Input Voltage VAC: 230V AC to 400V AC
- Product Range: -
- Power Supply Output Type: Fixed
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- SVHC: No SVHC (12-Jan-2017)
- Approval Bodies: EN, IEC, VDE
- External Depth: 94mm
- External Length / Height: 63mm
- External Width: 71mm
- Height: 63mm
- Input Voltage: 230VAC
- Input Voltage AC Max: 400V
- Input Voltage AC Min: 230V
- Length: 71mm
- Load Regulation: 21%
- Operating Temperature Max: 40°C
- Operating Temperature Min: 0°C
- Output Ripple and Noise Voltage pk-pk: 5%
- Power Supply Type: Linear
- Supply Frequency Max: 60Hz
- Supply Frequency Min: 50Hz
- Supply Voltage: 230V
- Supply Voltage Typ: 230V AC
- Weight: 510g
- Width: 94mm
