LEM - DHR 200 C420 - Current Transducer, DHR Series, Panel Mount, 200A, 1 %, 4-20 mA Output, 20 Vdc to 50 Vdc
- Sensor Output: Current
- Supply Voltage DC Min: 20V
- Supply Voltage DC Max: 50V
- Current Measuring Range DC: 0A to 200A
- Current Measuring Range AC: 0A to 200A
- Response Time: 150ms
- Accuracy %: 1%
- Product Range: DHR-C420 Series
- SVHC: No SVHC (15-Jan-2018)
- Accuracy: 1%
- Conductor Diameter Max: 32mm
- Current Consumption: 30mA
- Current Max: 600A
- Current Range AC: 200A
- Current Range DC: 200A
- External Depth: 25mm
- External Length / Height: 70mm
- External Width: 90mm
- Fixing Hole Diameter: 4.6mm
- Flammability Rating: UL94V-0
- Frequency Max: 6kHz
- Frequency Min: 20Hz
- IP / NEMA Rating: IP20
- Load Current Max: 30mA
- Operating Frequency Range: 20Hz to 6kHz
- Operating Temperature Max: 70°C
- Operating Temperature Min: -40°C
- Output: 4 - 20 mA dc
- Output Type: True RMS
- Supply Current: 30mA
- Supply Voltage Range DC: 20V to 50V
- Transducer Function: Current
- Weight: 260g
