DHR 500 C420 Current Transducer, 500A, 4-20mA O/P Lem

LEMUGS :DHR 500 C420 Code de commande:1002702

Prix:
Prix ​​promotionnel€364,36

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (15 unité)

Documents et téléchargements

description

LEM - DHR 500 C420 - Current Transducer, DHR Series, Panel Mount, 500A, 1 %, 4-20 mA Output, 20 Vdc to 50 Vdc

  • Sensor Output: Current
  • Supply Voltage DC Min: 20V
  • Supply Voltage DC Max: 50V
  • Current Measuring Range DC: 0A to 500A
  • Current Measuring Range AC: 0A to 500A
  • Response Time: 150ms
  • Accuracy %: 1%
  • Product Range: DHR-C420 Series
  • SVHC: No SVHC (15-Jan-2018)
  • Accuracy: 1%
  • Conductor Diameter Max: 32mm
  • Current Consumption: 30mA
  • Current Max: 1800A
  • Current Range AC: 500A
  • Current Range DC: 500A
  • External Depth: 25mm
  • External Length / Height: 70mm
  • External Width: 90mm
  • Fixing Hole Diameter: 4.6mm
  • Flammability Rating: UL94V-0
  • Frequency Max: 6kHz
  • Frequency Min: 20Hz
  • IP / NEMA Rating: IP20
  • Load Current Max: 30mA
  • Operating Frequency Range: 20Hz to 6kHz
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Output: 4 - 20 mA dc
  • Output Type: True RMS
  • Supply Current: 30mA
  • Supply Voltage Range DC: 20V to 50V
  • Transducer Function: Current
  • Weight: 260g
