DILA-22(110V50HZ,120V60HZ) RELAY, WITH 2N0+2NC EATON MOELLER

EATON MOELLERUGS :DILA-22(110V50HZ,120V60HZ) Code de commande:1110587

Prix:
Prix ​​promotionnel€61,39

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documents et téléchargements

description

EATON MOELLER - DILA-22(110V50HZ,120V60HZ) - Contactor, 6 A, Panel Mount, 415 V, DPST-NO, DPST-NC, 4 Pole

  • Load Current Inductive: 6A
  • Relay Mounting: Panel
  • Operating Voltage: 415V
  • Contact Configuration: DPST-NO, DPST-NC
  • No. of Poles: 4 Pole
  • Switching Power AC3: -
  • Switching Current AC1: 10A
  • Coil Voltage VAC Nom: 120V
  • Coil Voltage VDC Nom: -
  • Switching Power AC1: -
  • Load Current Resistive: 10A
  • Switching Current AC3: 6A
  • Product Range: DILA
  • SVHC: No SVHC (17-Dec-2015)
  • Approval Bodies: CSA, EN, IEC, UL, VDE
  • Coil Type: AC
  • Contact Current AC Max: 6A
  • Contact Current DC Max: 4A
  • Contact Current Max: 6A
  • Contact Voltage AC Max: 415V
  • Contact Voltage AC Nom: 415V
  • Current Rating: 6A
  • Dielectric Voltage Coil to Contact: 400VAC
  • Dielectric Voltage Contact to Contact: 400VAC
  • External Depth: 117mm
  • External Length / Height: 68mm
  • External Width: 45mm
  • Frequency Max: 60Hz
  • Frequency Min: 50Hz
  • Input Voltage Max: 120VAC
  • Input Voltage Min: 110VAC
  • Nom Operating Power: 300mW
  • Relay Type: Contactor
