COILCRAFT - DO3316T-222MLD - Power Inductor (SMD), 2.2 µH, 7.4 A, Unshielded, 7.8 A, DO3316T, 13.21mm x 9.91mm x 6.35mm
- Inductance: 2.2µH
- RMS Current (Irms): 7.4A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 7.8A
- Product Range: DO3316T Series
- Power Inductor Case: 13.21mm x 9.91mm x 6.35mm
- DC Resistance Max: 0.011ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 90MHz
