COILCRAFT - DO3316T-474MLD - Power Inductor (SMD), 470 µH, 500 mA, Unshielded, 500 mA, DO3316T, 13.21mm x 9.91mm x 6.35mm
- Inductance: 470µH
- RMS Current (Irms): 500mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 500mA
- Product Range: DO3316T Series
- Power Inductor Case: 13.21mm x 9.91mm x 6.35mm
- DC Resistance Max: 1.27ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 3.5MHz
