COILCRAFT - DO3340P-333MLD - Power Inductor (SMD), 33 µH, 2 A, Unshielded, 4 A, DO3340P, 12.95mm x 9.4mm x 11.43mm
- Inductance: 33µH
- RMS Current (Irms): 2A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 4A
- Product Range: DO3340P Series
- Power Inductor Case: 12.95mm x 9.4mm x 11.43mm
- DC Resistance Max: 0.08ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
