DRA1-CMX60D10 SSR, DIN Module, 60VDC, 8A SENSATA/Crydom

SENSATA/CRYDOMUGS :DRA1-CMX60D10 Code de commande:1784035

Prix:
Prix ​​promotionnel€92,88

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 4 produits disponibles

Documents et téléchargements

description

SENSATA/CRYDOM - DRA1-CMX60D10 - Solid State Relay, SPST-NO, 10 A, 60 VDC, DIN Rail, Cage Clamp

  • Contact Configuration: SPST-NO
  • Load Current: 10A
  • Operating Voltage Max: 60VDC
  • Relay Mounting: DIN Rail
  • Relay Terminals: Cage Clamp
  • Switching Mode: -
  • Operating Voltage Min: 1VDC
  • Control Voltage Min: 3VDC
  • Control Voltage Max: 10VDC
  • Product Range: -
  • SVHC: No SVHC (12-Jan-2017)
  • Control Current @ 5VDC: 15mA
  • Control Voltage DC Max: 10VDC
  • Control Voltage DC Min: 3VDC
  • Control Voltage Range: 3V DC to 10V DC
  • Control Voltage Type: DC
  • Isolation Voltage: 2.5kV
  • Load Current RMS Max: 8A
  • Operating Voltage Range: 1V DC to 60V DC
  • Peak Surge Current: 100A
  • RMS Load Current Min: 0A
  • RMS Load Voltage Max: 60V
  • RMS Load Voltage Min: 1V
  • Surge Current: 100A
