ECA2DHG101 Cap, 100µF, 200V, 20% Panasonic

PANASONICUGS :ECA2DHG101 Code de commande:9693220

Prix:
Prix ​​promotionnel€2,66

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (913 unité)

Documenten en downloads

description

PANASONIC - ECA2DHG101 - Electrolytic Capacitor, 100 µF, 200 V, ± 20%, Radial Leaded, 1000 hours @ 105°C, Polar

  • Capacitance: 100µF
  • Voltage Rating: 200V
  • Product Range: NHG Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 16mm
  • Lead Spacing: 7.5mm
  • Height: 25mm
  • Operating Temperature Min: -25°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 1000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: AEC-Q200
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 25mm
  • Lead Diameter: 0.8mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -25°C to +105°C
  • Ripple Current AC: 335mA
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 200V
