XP POWER - ECE40US15-SD - AC/DC DIN Rail Power Supply (PSU), ITE, 1 Output, 40 W, 15 VDC, 2.67 A
- No. of Outputs: 1 Output
- Output Power Max: 40W
- Output Voltage - Output 1: 15VDC
- Output Current - Output 1: 2.67A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Output Voltage - Output 4: -
- Current, Output 4: -
- Input Voltage VAC: 85V AC to 264V AC
- Power Supply Output Type: Fixed
- Product Range: ECE Series
- SVHC: No SVHC (15-Jan-2018)
- Applications: General Purpose
- Height: 28.5mm
- Input Frequency: 63Hz
- Input Voltage AC Max: 264VAC
- Input Voltage AC Min: 85VAC
- Length: 96mm
- No. of Outputs: 1Outputs
- Output Current: 2.67A
- Output Voltage: 15V
- Peak Output Current: 3.47A
- Power Rating: 40W
- Power Supply Type: Enclosed
- Width: 40mm
