XP POWER - ECL05US03-E - AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 4.3 W, 3.3 V, 1.3 A
- No. of Outputs: 1 Output
- Output Power Max: 4.3W
- Output Voltage - Output 1: 3.3V
- Output Current - Output 1: 1.3A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Power Supply Output Type: Adjustable, Fixed
- Input Voltage VAC: 85V AC to 264V AC
- Width: 27.2mm
- Height: 23mm
- Depth: 52.4mm
- Product Range: ECL Series
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 72%
- Input Voltage AC Max: 264V
- Input Voltage AC Min: 85V
- Input Voltage DC Max: 370VDC
- Input Voltage DC Min: 120VDC
- Length: 27.2mm
- No. of Outputs: 1Outputs
- Output Current Max: 1.3A
- Peak Output Current: 1.69A
- Power Rating: 4.3W
- Supply Voltage Typ: 110V AC, 230V AC
