XP POWER - ECL15US12-E - AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 15 W, 12 V, 1.25 A
- No. of Outputs: 1 Output
- Output Power Max: 15W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 1.25A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Power Supply Output Type: Adjustable, Fixed
- Input Voltage VAC: 85V AC to 264V AC
- Width: 33.3mm
- Height: 24.4mm
- Depth: 65mm
- Product Range: ECL Series
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CSA, cUL, EN, UL
- Efficiency: 80%
- External Depth: 24.4mm
- External Length / Height: 65mm
- External Width: 36.6mm
- Input Current: 0.3A
- Input Voltage AC Max: 264V
- Input Voltage AC Min: 85V
- Input Voltage DC Max: 370VDC
- Input Voltage DC Min: 120VDC
- Inrush Current: 20A
- Length: 24.4mm
- Line Regulation: 0.5%
- Load Regulation: 1%
- No. of Outputs: 1Outputs
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
- Output Current Max: 1.25A
- Output Ripple Voltage pk-pk: 120mV
- Peak Current: 1.62A
- Power Rating: 15W
- Power Supply Type: Switch Mode
- Supply Voltage: 264V
