description

XP POWER - ECL15UT02-S - AC/DC Enclosed Power Supply (PSU), ITE, 3 Outputs, 15 W, 5 V, 2 A, 12 VDC

  • No. of Outputs: 3Outputs
  • Output Power Max: 15W
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 2A
  • Output Voltage - Output 2: 12VDC
  • Output Current - Output 2: 200mA
  • Output Voltage - Output 3: -12V
  • Output Current - Output 3: 200mA
  • Output Voltage - Output 4: -
  • Current, Output 4: -
  • Input Voltage VAC: 85V AC to 264V AC
  • Power Supply Output Type: Fixed
  • Product Range: ECL Series
  • SVHC: No SVHC (15-Jan-2018)
  • Applications: General Purpose
  • Height: 26.4mm
  • Input Frequency: 63Hz
  • Input Voltage AC Max: 264V
  • Input Voltage AC Min: 85V
  • Length: 84mm
  • Output Current Max: 2A
  • Power Rating: 15W
  • Width: 34.5mm
