PANASONIC - EEEFK0J102AP - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 6.3 V, 2000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 1000µF
- Voltage Rating: 6.3V
- ESR: -
- Product Range: FK Series
- Lifetime @ Temperature: 2000 hours @ 105°C
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Ripple Current AC: 600mA
- Diameter: 8mm
- Height: 10.2mm
- Automotive Qualification Standard: AEC-Q200
- MSL: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance: ± 20%
- Capacitance Tolerance ±: ± 20%
- Capacitor Case Style: Radial Can - SMD
- External Length / Height: 10.2mm
- External Width: 8.3mm
- Frequency Tolerance: 120Hz
- Impedance: 0.16ohm
- Impedance Frequency: 100kHz
- Impedance Temperature: 20°C
- Lead Cross-section Width: 0.9mm
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 1000h
- Power Factor: 0.26
- Power Factor Frequency: 120Hz
- Power Factor Temperature: 20°C
- Reel Quantity: 500
- Ripple Current Frequency: 100kHz
- Ripple Current Temperature: 105°C
- Tape Width: 16mm
- Tolerance +: 20%
- Tolerance -: 20%
- Tolerance Temperature: 20°C
- Voltage Rating V DC: 6.3V
