EEEFK1E330UR Cap, 33µF, 25V, Radial, SMD Panasonic

PANASONICUGS :EEEFK1E330UR Code de commande:9695745

Prix:
Prix ​​promotionnel€0,50

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (3186 unité)

Documents et téléchargements

description

PANASONIC - EEEFK1E330UR - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 33 µF, 25 V, 2000 hours @ 105°C, Polar

  • AE Capacitor Case: Radial Can - SMD
  • Capacitance: 33µF
  • Voltage Rating: 25V
  • ESR: -
  • Product Range: FK Series
  • Lifetime @ Temperature: 2000 hours @ 105°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Ripple Current AC: 160mA
  • Diameter: 5mm
  • Height: 5.4mm
  • Automotive Qualification Standard: AEC-Q200
  • MSL: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance: ± 20%
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Case Style: Radial Can - SMD
  • External Length / Height: 5.4mm
  • Impedance: 0.7ohm
  • Operating Temperature Range: -55°C to +105°C
  • Operating life Time: 2000h
  • Power Factor: 0.14
  • Power Factor Frequency: 120Hz
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 25V
