EEUED2V470 Cap, 47µF, 350V, 20% Panasonic

PANASONICUGS :EEUED2V470 Code de commande:9696440

Prix:
Prix ​​promotionnel€3,48

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (91 unité)

Documents et téléchargements

description

PANASONIC - EEUED2V470 - Electrolytic Capacitor, 47 µF, 350 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar

  • Capacitance: 47µF
  • Voltage Rating: 350V
  • Product Range: ED Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 16mm
  • Lead Spacing: 7.5mm
  • Height: 25mm
  • Operating Temperature Min: -25°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 10000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 25mm
  • Lead Diameter: 0.8mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -25°C to +105°C
  • Operating life Time: 10000h
  • Ripple Current AC: 800mA
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 350V
