PANASONIC - EEUEE2E820S - Electrolytic Capacitor, 82 µF, 250 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar
- Capacitance: 82µF
- Voltage Rating: 250V
- Product Range: -
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 18mm
- Lead Spacing: 7.5mm
- Height: 20mm
- Operating Temperature Min: -25°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 10000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: AEC-Q200
- SVHC: No SVHC (07-Jul-2017)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 20mm
- No. of Pins: 2Pins
- Operating Temperature Range: -25°C to +105°C
- Ripple Current AC: 1680mA
- Ripple Current Frequency: 100kHz
