EEUFM1C102 Cap, 1000µF, 16V, 20% Panasonic

PANASONICUGS :EEUFM1C102 Code de commande:1219463

Prix:
Prix ​​promotionnel€1,08

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (21877 unité)

Documents et téléchargements

description

PANASONIC - EEUFM1C102 - Electrolytic Capacitor, 1000 µF, 16 V, ± 20%, Radial Leaded, 5000 hours @ 105°C, Polar

  • Capacitance: 1000µF
  • Voltage Rating: 16V
  • Product Range: FM Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 10mm
  • Lead Spacing: 5mm
  • Height: 20mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 5000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 20mm
  • Impedance: 0.019ohm
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.6mm
  • Lead Length: 17mm
  • Leakage Current: 0.01µA
  • No. of Pins: 2Pins
  • Operating Life Temperature: 105°C
  • Operating Temperature Range: -40°C to +105°C
  • Operating life Time: 5000h
  • Ripple Current AC: 2180mA
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 16V
