EEUFR1E222L Cap, 2200µF, 25V, 20% Panasonic

PANASONICUGS :EEUFR1E222L Code de commande:1800658

Prix:
Prix ​​promotionnel€1,70

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (6114 unité)

Documents et téléchargements

description

PANASONIC - EEUFR1E222L - Electrolytic Capacitor, 2200 µF, 25 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar

  • Capacitance: 2200µF
  • Voltage Rating: 25V
  • Product Range: FR Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 12.5mm
  • Lead Spacing: 5mm
  • Height: 30mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 10000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • Impedance: 0.013ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.8mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +105°C
  • Ripple Current AC: 3630mA
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
