Egg.0K.305.CLL Socket, Panel, 5WAY Lemo

LEMOUGS :EGG.0K.305.CLL Code de commande:8387478

Prix:
Prix ​​promotionnel€47,28

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (18 unité)

Documents et téléchargements

description

LEMO - EGG.0K.305.CLL - Circular Connector, 0K Series, Panel Mount Receptacle, 5 Contacts, Solder Socket, Push-Pull

  • Product Range: 0K Series
  • Circular Connector Shell Style: Panel Mount Receptacle
  • No. of Contacts: 5Contacts
  • Circular Contact Type: Solder Socket
  • Coupling Style: Push-Pull
  • Connector Body Material: Brass Body
  • Connector Body Plating: Chrome
  • Contact Material: Bronze
  • Contact Plating: Gold
  • SVHC: No SVHC (07-Jul-2017)
  • Body Plating: Chrome
  • Connector Mounting: Panel Mount
  • Connector Type: Circular Industrial
  • Contact Gender: Socket
  • Contact Plating: Gold Plated Contacts
  • Contact Resistance: 4.1mohm
  • Contact Resistance Max: 4.8mohm
  • Contact Termination: Solder
  • Contact Termination Type: Solder
  • Current Rating: 6.5A
  • Gender: Receptacle
  • IP / NEMA Rating: IP66
  • No. of Mating Cycles: 5000
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -20°C
  • Test Voltage Contact / Contact: 1000V
