ER58R22JT Res, 0R22, 5%, 7w, Axial, Wirewound CGS - Te Connectivity

CGS - TE CONNECTIVITYUGS :ER58R22JT Code de commande:1751870

Prix:
Prix ​​promotionnel€2,94

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (479 unité)

Documents et téléchargements

description

CGS - TE CONNECTIVITY - ER58R22JT - Through Hole Resistor, 0.22 ohm, ER, 7 W, ± 5%, Axial Leaded, 200 V

  • Resistance: 0.22ohm
  • Product Range: ER Series
  • Power Rating: 7W
  • Resistance Tolerance: ± 5%
  • Resistor Case Style: Axial Leaded
  • Voltage Rating: 200V
  • Resistor Element Material: Wirewound
  • Temperature Coefficient: ± 200ppm/°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Body Diameter: 8mm
  • Body Length: 22.2mm
  • Lead Diameter: 0.8mm
  • Lead Length: 38mm
  • No. of Pins: 2Pins
  • Operating Temperature Max: 200°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +200°C
  • Resistor Mounting: Through Hole
