IMO PRECISION CONTROLS - FA4501-2DN - Limit Switch, Plunger, 1NO / 1NC, 6 A, 500 V, 10 N, FA
- Limit Switch Actuator: Plunger
- Contact Configuration: 1NO / 1NC
- Contact Current AC Max: 6A
- Contact Voltage AC Max: 500V
- Operating Force Max: 10N
- Product Range: FA Series
- Contact Current DC Max: 2.5A
- Contact Voltage DC Max: 600V
- SVHC: No SVHC (07-Jul-2017)
- Actuator Type: Piston Plunger
- Contact Current Rating: 6A
- External Depth: 16mm
- External Length / Height: 40mm
- External Width: 30mm
- Fixing Centres: 20mm
- IP / NEMA Rating: IP67
- Lead Length: 2m
- No. of Mechanical Operations: 20000000
- Operating Force: 10N
- Operating Temperature Max: 75°C
- Operating Temperature Min: -25°C
- Pre-travel: 2mm
- Switch Operation: Off-On
- Switch Terminals: Cable
- Thermal Current Rating: 10A
